Capacitor (16th Day)

Spring 2015
Professor Mason
April 28 Class

Circuit Calculation in Quiz

First thing we did in class was a quiz about calculating V, I, R, and Power in a circuit. R1 and R2 were given; in order to find both I1 and I2, we had to use loop formula, which was equation 1: [E1 - E2 + 320 I2 = 0] and equation 2: [E2 - 510 I1 - 320 I2 = 0]. By plugging in the numbers and substituting the variables, we got I1 equals to 0.037 A, I2 equals to -0.022 A, and I3 equals to 0.059 A. After we finished calculating the I, we could use [V = IR] formula in order to get the V. After we got all the R, V, and I, we could finally calculate the power by using [P = IV] or we could simply say [P = I^2 R]. Then, the total P is just P1 + P2 (J/s).

Capacitor

When a capacitor is attached to a battery, it acts similar to the battery; the positive charge and negative charge are attracted to each other. As shown in the picture attached above, if the battery is attached to a capacitor, [Vb = Vc]; it means that the voltage unit in the battery is the same as the capacitor. If no battery is attached, there is no flow going through the circuit; thus, when we attach a light bulb in the circuit, there would be a flow going through the bulb, and it will make the bulb light. Capacitor is defined as an equation of [C = Q / V], which C is the capacitor, and Q/V is the stored charge per voltage unit. C is defined with a unit of Farad, Q is defined with a unit of Coulomb, and V is defined with a unit of Voltage. Stored energy has a definition of [delta U = Work = Integral of V dq = Integral of Q/C dq = Q^2/2C]. [Q^2/2C] could also be simplified to [CV^2/2]. If the area of the capacitor is increased, the capacitor is also increased, which means that Area is perpendicular to Capacitor. It also happens with distance; the shorter the distance is, the larger the capacitor is, which means that C is perpendicular to 1/d.

Capacitor experiment

In class, we needed to do an experiment that involves two sheets of aluminum foils, a book, and something heavy to push down the book and capacitor so it would measure accurately. First, we need to place two sheets of the foils in between the book pages; then, we put the positive and negative charges of the machine and put it to the foils, so that it would measure in terms of nano Farad (nF). The data we received were written in the book, and these are the data: (1 page = 1.22 nF, 3 pages = 0.8, 5 pages = 0.68, 7 pages = 0.63, 9 pages = 0.54, 11 pages = 0.52, 13 pages = 0.47, 15 pages = 0.44, and 17 pages = 0.41 nF); 1 page is equal to 0.078 mm. The graph is shown in the picture attached above.

We could also calculate the capacitor using [C = k Eo A / d], which k comes from [Epsilon = k Eo], and k is the permittivity (permittivity of paper is 3.5); Eo is the constant. Paper does not have the same permittivity as air, so it would have different value when the distance between two capacitors are filled with air.

The calculation shown in the picture above is the formula to calculate the area if k, Eo, C, and d are given; Eo and k would be different depending on the material we use.

 For the calculation part, we were given this picture shown on the left; we needed to find the C and the V given that the charge (Q) in series setup is equal to each other. C in series setup is the same as R in parallel setup and vice versa. For the picture on the left, we first needed to find the charge in C2 because it equals to the charge in C1; then we could find the voltage C2. Therefore, we could find the V in  battery.  For the last picture, we found out that we could find the work done using[1/2 CV^2].

Capacitor in different kind of functions

In class, we found out that the definition of electric field around capacitor is equal to [E = V/d], which V is the voltage unit, and d is the distance. For spherical Capacitor, the equation for it is [C = (R1 R2)/ (k (R2 - R1))]. Next in class, we discussed about dielectrics strength and constant; the unit of dielectrics strength is (V/m), and the constant is [k = E/Eo]. Finally in class, we needed to measure the C value for each capacitor, with two capacitor given. The measurement was parallel = 2.11 uF, series = 0.52 uF, and each of them has 1.06 uF; therefore, we found out that parallel setup is just the sum of both capacitor, and series setup is the half value of individual capacitor.

Resistors, Kirchhoff's Law, and Ohm's Law (15th Day)

Spring 2015
Professor Mason
April 21 Class

Electric Potential in Diagram

The first thing we did in class was about analyzing sketch or diagrams of how electric potential in a set of batteries and light bulbs. For the first sketch in the picture shown below, we were asked what would happen to light bulb #1, #2, and #3 if the switch next to light bulb #2 is turned on. The answer is when the switch is turned on, light bulb #1 would light brighter, light bulb #2 would light dimmer, and finally light bulb #3 would not light at all. It happens because (Electric Potential in each batteries is 1.5V) the positive charge of the battery goes through light bulb #1 first, so that light bulb #1 would light brighter. Then, both electric potential that went through bulb #1 and #3 cancels each other out; therefore bulb #2 would not light at all. The same method also applies for the second sketch; we were asked to predict what would happen to each light bulb. The result was that light bulb #1 and #2 light the same because they both have equal electric potential running through the bulbs.

 Voltage Law and Current in Batteries

 In class, we learned Voltage Law based on the lab manual. We found out that the definition of Voltage Law is the sum of voltages around the circuit equals to zero [sigma V = 0] (as shown in the picture above); another word for Voltage Law is Vin - Vout = 0. The same equation for Current Law goes the same as Voltage Law, which is the sum of amperes around the circuit equals to zero [sigma I = 0].

 We also did a question based on the lab manual, which asked for how the bulb and batteries would set up in terms of dim and bright. The result for that question is shown in the picture attached above. Series setup of bulbs would make the bulbs light dimmer; however, series setup of batteries would make the bulbs light brighter. On the other hand, parallel setup of bulbs would make the bulbs light brighter; however, parallel setup of batteries would make the bulbs light dimmer. We also found out an equation in terms of voltage and current is [P = IV], which P is the brightness, I is the current, and V is the voltage.

Color Bands in Resistors

In class, we learned that resistors use color bands to identify their values instead of using numbers because placing numbers in the resistor would be really small and really hard to read. We also learned how to read the numbers in resistors based on the colors given. We learned that: we have to read the band from left to right; Color band 1 resembles the first digit (Ex: 4), color band 2 resembles the second digit, color band 3 resembles the multiplier (Ex: x10^2), and finally color band 4 resembles the uncertainty (Ex: plus or negative 2). We also learned that in order to measure a series or parallel of resistors, we have to twist the end of each resistors together to combine them together. Resistance in series setup adds together (sum), while resistance in parallel is multiplier or divider depends on how many resistors there are (2 resistors: divide the result by 2, 3 resistors: divide the number by 3). We measured each resistors by using the machine shown in the picture attached on the left. We placed the two very tip of the wires to the end of each resistors in order to measure them. For experiment, we were given four different resistors; we needed to measure each one of them, and the results are shown in the picture below.
To answer the question "Did your resistor match the color coded value with uncertainty?", the answer is yes, they all matched the color coded value with uncertainty.

Kirchhoff's Law
After we learned the lecture from Professor Mason, we found out that Kirchhoff's Law is about loop in a sketch. We also learned that in parallel setup, I in (flow in) is equal to I out (flow out) in a loop. Two easy steps to learn the basic of Kirchhoff's Law is first, we have to assign the currents, then followed by applying loop rule for each loop. We also know for sure that the flow going up is most likely positive, and the flow going down is most likely negative. The three basic equations for the setup below are: [V1 - I2 R2 - I1 R1 = 0], [I2 R2 - I3 R3 - V2 = 0], and [Current = I1 = I2+I3], based on the variables given around the setup. Equation may vary depending on the setup. These equations are based on one equation, which is [V = IR].

Vpython Electric Potential

Spring 2015
Professor Mason
VPython Electric Potential

In class, we were asked to modify VPython's program from a regular and simple code to a more complicated loop code. This is how the new code looks like after we spent a lot of time coding it.

 First, we had to make a formula for r1 and V1 in order to calculate the electric potential in charge 1, followed by r2, V2 and r3, V3 shown in the picture attached below; r1, r2, r3 are the radius from each charge to the smaller sphere (observation point) that would show up later on after we finished the loop (the observation points would encircle around the 3 charges). Next, we created a while loop for each equation of charges, followed by the domain, such as how many observation points would encircle the 3 main charges; we decided to make loop for 20 times circling around the 3 main charges until it gets to 2pi in order to stop.

After we finished the first loop for each charges, we had to create the second loop in order to calculate the sum of the total electric potential circling around the 3 main charges. However, when we attempted to create loop for the sum, we failed, and the code did not work as planned, which is shown as #rednote in the picture attached above. Therefore, we created another loop, which define x, y , w equal to 1 and put a while loop in order to calculate it manually by putting all the numbers shown in the output as a list. After we made a list of those outputs, we had to calculate the sum, so we used sum(variable). Then, we had to use float in order to calculate the remaining decimals. We also had to put break at the end of the loop in order to prevent the infinite loop.

This is how it looks after we run the module with that code:

The picture attached above shows what the outputs are for the coding we created. The 20 numbers listed are the numbers for V1, V2, V3 after calculating the loop of electric potential for 20 times. Then we also provided the total sum of those electric potential in each charges. Then, we also calculated the total sum of all electric potential, which we put at the very end of the output. The diagram would look like this in the picture shown below. The cyan colored spheres are the observation points encircling around the red,  green, and blue colored spheres.

Electric Potential (14th Day)

 Spring 2015
Professor Mason
April 16 Class

Electric Potential in Microsoft Excel
The first thing we needed to do in class was to calculate the electric potential of 20 charges in excel by using an equation of [V = kq/(sqrt of a^2 +x^2)], given a is 0.3 and x is 0.2, while k is a constant of 9e9 and q is a charge that is 2e-5.After we got one charge by using the calculation, we could just copy the whole numbers for 20 times, and calculate the total as shown in the picture attached on the left. Potential difference happens due to continuous charge distributions. We did another experiment with excel in the middle of the class after the first one. However, this one is more complicated because it is based on a triangle shown on the picture attached below. There is a rod, and the rad has 20 charges attached in it .We had to calculate the electric potential in the 16th charge, but it started at in the middle of charge 0 and charge 1; therefore we measured it from 0.5 to 16th charge in excel.

 Electric Potential Calculations
After we did an experiment with Microsoft Excel, we did another calculation by hand, given the picture as shown below. The ring has 20 point charges acting on a single point x distance from ring. Ring has a radius of a. Given the charge for 20 charges is 20 micro C, therefore, we had to divide it by 20 and multiply it by 20 because it has 20 charges. We used the same equation as the one in Microsoft Excel, which is [V = kq / sqrt (a^2 + x^2)].

 On the next one, we were asked to calculate the electric potential in terms of theta as shown in the picture below. We knew that the diameter of that circle is 2a, and the distance from the edge of that diameter to P2 is defined by x. Therefore, we found out that [tan theta = 2a/x ], [sin theta = 2a / sqrt(4a^2 + x^2)], and [cos theta = x / sqrt (4a^2 + x^2)]. After we substitute and simplify the formula, we found out that the electric potential in terms of theta could be [V = kq cos theta / x] as shown in the picture below.

 After we finished with all the electric potential calculations, we were asked to draw an equal electric potential in a circle, and the result is shown below in the picture. Other than that, we were also asked to draw an equal electric potential between two rods, and we found out that there are several answers for it, and the result vector is shown in the picture attached below.

Electric Measurement Experiment

 In this experiment, we knew for sure that positive charges is always going towards negative charges. First, we set up the power supply to 15 V, then connect all the wires to the yellow wires shown in the picture above. We also needed to connect another wire to the red machine in the picture above. We used the tip of the wire that are connected to the red machine, and place it on the metal that is attached to the yellow wires. We had to measure the numbers shown in the red machine from a certain point to another certain point. Next, we had to make a table based on the numbers we got from the red machine in order to calculate the electric potential total of this experiment.

Work, Energy, and Electric Field (13th day).

Spring 2015

Professor Mason

April 14 Class

Battery and Bulb Experiment

The first thing we learned in class was about doing an experiment involving two batteries and two light bulbs attached with circuits. We were asked to figure out which one was the brightest and which one was the dimmest, and we had to make a sketch out of it. As we can see on the pictures attached, the batteries that were set up series had the brightest light; on the other hand, the one which was set up parallel had the dimmest light. Parallel set up batteries is more efficient because it gives higher current but lower voltage so it does not take much amount of energy from the batteries; on the other hand, series set up batteries has higher voltage but lower current, and it uses up energy from batteries faster than parallel, but it has brighter light. As for the sketch, we uses symbols as simple as possible as shown in the picture attached.

Joule's Law

In class, we did an experiment about water heater. We needed to know three important things about the water while heating the water, and those are mass, power, and time. The steps are observe change of temperature in water for two minutes, double the voltage, and finally observe the change of temperature for two more minutes. The graph looks like the pictures attached below.

The red colored graph is a graph showing water at room temperature being stirred, while the blue colored graph shows how crucial the difference is when the water is heated. We found out the equation for Joule's Law is [P = I^2 R], which was broken down from [P = VI] and [P = V^2/R]. We also found out that the definition of Colomb is how charge falls towards other charge in an atom.

Work done

In class, we discussed things about work done in many functions. We found out that the equation for work done is [W = integral from a to b of F ds]. We were also given a question to calculate by hand about work given a picture of triangle and an object that we were supposed to sketch a diagram first. It turned out to be like the pictures attached above.

First, we had to figure out what we calculate, which was Wabc equals to the sum of Wab and Wac. We found out that [Wac = F (h/sin 30) *cos60], however, sin 30 and cos 60 cancels out each other, so it becomes F*h; therefore, Wabc = Fh.

Work as a function of electric field has an equation of [W = integral from a to b of qe E ds]. We also needed to define which one has the biggest work done and the lowest work done based on the picture above; the result was B has the least amount of work done, followed by C and A, which A has the biggest work done. Based on the calculation before, we found out that the work done on each particle [A = q E d], [B = 0 (because line B is perpendicular, thus work is equal to zero], and [C = q E d cos (theta)], which d is distance.  Work is also equals to change of energy (delta U). Potential energy of point charge has an equation of [ q h (Q/r) + C] and potential energy of electrical has an equation of [q k (Q/r)] or [integral from a to b of q E ds]. We also needed to write an equation of voltage based on the potential energy equation above. The result is [V = (k Q)/r] or [V = integral from a to b of E ds], which [V = PE elec/q] were given first; therefore, we just needed to cancel out the q. Work is also equal to [q (V2 - V1)]. Work and Voltage equation as an electric potential energy and electric field has a form of [W = integral from a to b of - q E ds] and [V = integral from a to b of - E ds + C] or [E = dV/ds].

VPython

The last thing we needed to do in class was about VPython. We were given a set of codes for VPython, and we first needed to predict the outcome of that code by sketching a graph. The picture attached shows how it looks like after we predicted the outcome. We also needed to calculate the Voltage by hand by using [V = k q /r], which k is a constant (9x10^9), q is the charge given in the code, r is the distance from the observation location to charge 1 and charge 2. We needed to find V1 and V2 based on the given code.

Next, we needed to create our own code and sketch a graph based on our own code, however, this time we needed to create three charges instead of two. The picture attached below basically shows the foundation of the code in order to create three charges and three observation locations. Then, we needed to calculate the Voltage by hand, therefore, we spend a lot of time calculating from V1 to V3 based on the given code.

Electricity, current, and resistivity (12th day).

Spring 2015

Professor Mason

April 9th class

Light Bulb and Energy

First thing in class, we needed to make a sketch of the set up between battery, light bulb, and wire. We first needed to sketch two ways of how the light bulb would light by using the battery and wire. Then, we also needed to make two sketches of how the bulb would not light up and also the reasons. It would light up because the electricity is going through positive and negative charges through the wire. It would not light up because there is no flow going through the positive and negative charges. We could also double the light by putting two batteries together. We also did an experiment with electroscope machine, and we were asked to predict what would happen if we put two batteries on the tip of that machine, and the result was nothing happened.

We learned that the fundamental definition of energy is the capacity to do work using energy. For example, the battery is giving energy and the bulb is using it up.

Another experiment with battery, wire, and light bulb is making a circuit, so the bulb would light up. We need the second wire for this experiment to go back from the bulb to have positive and negative charges working together in order for the force to go in one direction. We need it to have equilibrium of the charges.

Voltage, Current, and Power

In class, we had an imaginary experiment dealing with waterfall and hydro electric generator. We need the flow of water in order to run the generator; however, there are two things that we should know about the waterfall, and those are the potential energy and the flow rate. We need a faster and heavier waterfall, which we could get from rising the height of the water fall; then, we need to have a bigger rate of flow of the waterfall in order to run the generator. We come up with an equation of voltage, flow rate (current) and power [V = J/C] or energy per unit charge, [I = C/s] or Ampere = Charges per second, and [P = J/s] or energy per unit time. The relationship between Voltage, Flow Rate, and Power is [P = I V] or Voltage times Current, which will become J/s in the end. Then we need to do a calculation to find the P, which I and V are already given. For example, the I is 12 mA (mili Ampere) and V is 1.5V (Volt), so that P is [0.12 * 1.5 = 0.18 J/s].

Next, in class, we were given a question, which asked us to pick the correct one from model A to model D. We chose model D as in the lab manual showed us because the direction of the current will be shown and it will be the same in both wires, which means the current going in and out are the same.

Current in the wire [I = dq/dt] (C/s) = Ampere.

We did an experiment in class, which required us to deal with ampere meter. The picture on the right is how the tools are set up. We set up the wire from the negative charge of the battery to the positive charge of the ampere meter; then, we put two wires from the battery (+ and -) and attach them to the light bulb circuit. After that, we attach one of the circuit to the ampere meter.

Drift Velocity and Current and Ohm's Law
Today, we found out the equation of Current with the function of drift velocity is [I = RHOn q Vd A], which RHOn is the density (charges per unit volume), q is the charge of electron, Vd is the drift velocity, and A is the cross-sectional area perpendicular to the flow (the thicker the wire, the easier the flow is). In class, we also needed to draw graph  I vs V and V vs I; it looks like the picture attached. The equation of the slope is [m = dV/dI] or the derivative of V/I.

Resistance

We also learned resistance in class, which we come up with an equation of [V = I R], which R is the resistivity. The longer the wire, the bigger the resistance is. It also depends on the Area of the wire. For example, wire 1's length is 200cm and has a diameter of 0.25cm; wire 2 has a length of 200cm as well and has a diameter of 0.32cm. The smaller the area is, the bigger the resistance is; therefore, in this case, the wire with the diameter of 0.25cm has a bigger resistance, whilst R is proportional to Length.

Resistance is proportional to the material as well (copper is good conductor, so the bigger the conductivity is, the smaller the resistance is). It also depends on the length and the area, which leads to an equation of [R = Rho L/A], which Rho is the resistivity, L is the length, and A is the area of the wire.

Resistance as a function of temperature has a formula of {R = Ro[1+alpha(T-To)]}, which alpha is the temperature coefficient, and it depends on the type of metal. The colder the temperature is, the easier for the electron to go through; as the temperature increases, the resistance increases because there is more collision happening in the wire, thus resistivity is proportional to temperature.
